ANSI B16.5 PN16 1500LB DN3000 Forged Steel Plate Flanges
Description:
Full pipe flow, when they flow through the pipe of the throttle
device, a beam to local contraction at the throttling of the
throttle device, so that the flow velocity increases, the static
pressure is low, so the throttling parts before and after the
pressure drop is produced, the pressure difference, the greater the
flow of medium flow, the throttling produce the greater the
pressure difference before and after, so can be measured by the
size of the pressure difference to measure fluid flow. This
measurement method is based on the law of energy balance and the
law of flow continuity.
Intelligent throttle device (flowmeter) is a new generation of
flowmeter which integrates the function of flow, temperature and
pressure detection and can automatically compensate the temperature
and pressure. The meter adopts advanced microcomputer technology
and new micro power consumption technology, with strong function,
compact structure, simple operation and convenient use.
The characteristics of
Throttling device structure is easy to copy, simple, firm, stable
and reliable performance, long service life, low price.
The orifice plate calculation adopts international standard and
processing
Wide application range, all single - phase flow can be measured,
some miscible flow can also be used.
The standard throttling device can be put into use without real
flow calibration.
The one-type orifice plate is more simple to install, without
pressure lead tube, can be directly connected to the differential
pressure transmitter and pressure transmitter.
Specifications:
| Steel flange type | ASTM A105 American standard GB carbon steel orifice flange |
| Standard for flange materials | SA105/105M |
| The flange of | A105 |
| The flange class | 150LB, 300LB, 400LB,
600LB,900LB,1500LB,2500LB,PN6,PN10,PN16,PN25,PN40 |
| Flange sealing face | RF, FF,RTJ,TG,MFF,LF,LM,TF,GF, |
| The standard of the flange | ASME/ANSI B 16.5
|
| The flange thickness | SCH10S-50MM |
| Flange seal | According to customer requirements |
| Flange heat treatment | Is the fire |
| Application field of flange | It is used in petroleum, chemical industry, nuclear power plant,
food manufacturing, construction, shipbuilding, paper making,
medicine and other industries |
FAQ:
Q1: How to order?
1. To specity standard and the thickness.
2. To specity surface treatment.
3. To specity figure size and quantity.
Q2: After sales service?
Quality are promised.We have a dedicated after-sales department to
be responsible for all subsequent work after delivery.
Q3: Can I have a sample order for pipe fittings?
Yes, we welcome sample order to test and check quality.Mixed
samples are acceptable.
Q4: Do you offer guarantee for the products?
Yes, we offer almost 20 years warranty to our products.
